Lara
| Lara (itemtype) | |
|---|---|
| Name | Lara |
| TR1 ID | 0 |
| TR2 ID | 0 |
| TR3 ID | 0 |
| TR4 ID | 0 |
| TR5 ID | 0 |
| Appears in | All levels |
| Image |  |
Model Bone Indices
Copied from OpenTomb's Lua scripts.
-- .=. -- | 14| -- \ / \ -- / | | \ -- 11 / | 7 | \ 8 -- / | | \ -- | ===== | -- 12 | ===== | 9 -- | / 0 \ | -- 13 0 /_______\ 0 10 -- | | | | -- |1 | |4 | -- | | | | -- |__| |__| -- | | | | -- |2 | |5 | -- | | | | -- |__| |__| -- 3 |__| |__| 6 ----------------------------
Transform properties
| Notation | Description |
|---|---|
| $Head_{x,y,z}$ | Additional head bone rotation. |
| $Torso_{x,y,z}$ | Additional torso bone rotation. |
| $Lara_{x,y,z}$ | General transform position. |
| $Lara^\measuredangle_{x,y,z}$ | General transform rotation. |
| $\Delta Lara^\measuredangle_{x,y,z}$ | Values added to $Lara^\measuredangle_{x,y,z}$ on each frame. |
| $\uparrow Lara^\measuredangle_y$ | Lara's movement direction ($y$ angle), independent from her rotation. |
